Here we are with another innovative bolt in roll bar. This time around it’s for the BMW E92 M3! We’re proud to offer the strongest, safest, best designed bolt in roll bar on the market. We design all of our bars with safety as the first concern. Don’t fall for the less expensive bars on the market. They don’t match our well thought out design and construction.
As with all Cantrell Motorsports products, our main goals are always safety and overall product quality. This bolt in roll bar for the BMW E92 M3 is the safest, best fitting bolt in application on the market. The rear mounts bolt to the upper rear shock towers providing the safest possible mounting point.
Steel or Chromoly 1.75″ tubing (your choice)
Tig welded
1/4″ thick mounting plates for added rigidity
Rear points mount to vehicle shock towers
Works with factory or aftermarket seats
Our Standard powder coat color is T002-BK08 Matte Black #27038 20% Gloss powder coat and cost is $250. Refer to Color chart next row.
Custom powder coat color there is an additional $250 charge. See Color Chart here
Your rollbar can be professionally painted any color for an additional charge. Contact us for a quote.
PATENT PENDING DESIGN
We highly recommend CMS rollbars are only installed by shops that have experience installing roll bars. Cantrell Motorsports can most likely direct you to a installation shop in your area.
If an order includes smaller items which will fit in our Roll Bar box, your freight charge will corrected to the $300 Truck Rate price when your order processed.
For multiple quantities of any Bolt-in Rollbars to the same location, please contact us for a freight quote.
Truck Freight out of the USA: any duties, taxes and/or fees are paid by the purchaser.
Dealer Inquiries Welcome. Please contact us for requirements
Important info about Harness Bar Location
Our harness bar is located closer to the back of the seats as compared to others because we took into account as that is what the major racing harness manufacturers want to see. They want no more that 8″ between the shoulder harness mount and the back of the seat. Please read Schroth Racing shoulder belt Routing guidelines below.
SHOULDER BELT ROUTING (APPLIES TO ALL RESTRAINT TYPES)
Shoulder belts must run from the shoulders horizontally or down, at no more than a 20° angle. In cases where the shoulder belts must be routed down to the chassis floor, support by a roll cage bar or harness guide at the appropriate height is essential to establish the horizontal shoulder strap routing off the shoulder/HANS®. Most racing seats are not designed and tested to carry shoulder belt crash loads from downward installation. Severe injury or death could result. A 45° downward shoulder belt installation is possible with seats that SCHROTH has positively tested to take a load measured during a 50 kph [31 mph] and 28 G impact with a 75 kg (175 lb) dummy. Refer to the list of SCHROTH approved racing seats in section “About Seats”. WARNING: 45° downward shoulder belt installation is not recommended with HANS®.
For the best restraint of the occupant’s upper torso, ideal anchor points should not be further back than 200 mm [8”] from back of user’s seat.
